Hammond Large Shank Trombone Mouthpieces
|
Marking
|
Diameter
|
Bach*
|
Schilke*
|
|
10
|
1.030
|
3
|
53
|
|
11
|
1.020
|
4
|
52
|
|
12
|
1.010
|
5
|
51
|
|
13
|
1.000
|
6
|
50
|
|
14
|
.972
|
7c
|
-
|
|
19
|
1.068
|
1 1/2
|
58
|
|
20
|
1.125
|
1 1/4
|
59
|
|
21
|
1.140
|
1
|
60
|
|
M
|
Medium-depth cup with a V shape. This is an extremely efficient cup with the capability of duel use between section work or possibly lead on small bore, or solo work on large bore. .257 throat/T2 backbore (small bore), .265 throat /T5 backbore (large)
|
|
|
ML
|
This is the standard cup within the Hammond Design trombone line. It has aspects of both conical and bowl shapes to help become the all-around choice of most players looking for a focused, yet colorful sound. .265/T3 small bore, .281/T4 large bore.
|
|
|
L
|
This cup is deeper than the ML, but with the same shape carried further down in the mouthpiece. For those players needing more low end in their sound or for the principal player needing more "space". .281/T4
|
|
|
XL
|
Extremely deep cup that is a great euphonium set-up. The 12XL is the 51D comparison players have requested. .281/T4
|
|
|
BL
|
This is a large cup diameter with large cup depth. This is a bowl-shape with a funneled entrance to the throat for a very open feel, but with the control of a shallower cup. .316/BT
|
|
|
BXL
|
Very deep bowl shape cup but features the funneled entrance to the throat like the BL. This is the big boy! .316/BT
|
|
